Roland TM-1 Trigger Module

Roland TM-1 Trigger Module
Product no: 9000-0049-3105 Bax Music Warranty: This product comes with a 3-year warranty.

General

Roland's TM-1 is a trigger module that's perfect for adding extra sounds to your acoustic drum kit. It has 2 trigger inputs that can be used with drum and pedal triggers as well as drum and cymbal pads. The TM-1 has 30 sounds on board with room for another 30 of your own too. The sensitivity, pitch, decay and level can be easily adjusted using the built-in knobs. Loading samples and making extra adjustments can be done using the free TM-1 editor app that's available for Mac,Windows and iOS/Android.

Tips or comments about this product

Please note: the editor app for Android will be available from March 2019
To make a connection with an iOS device, you'll need a Lightning to USB camera adapter.
To make a connection with an Android device, you'll need a USB OTG adapter

Specifications

Product features

Sustainable product	not specified
Number of trigger inputs	< 2
Sound source	samples
Built-in sampler	no
Headphone output	yes
Supports USB media	no
USB port	yes
MIDI & other	MIDI over USB
Audio over USB	no
Includes cable	no

Weight and dimensions including packaging

Weight (incl. packaging)	800 gr
Dimensions (incl. packaging)	21,8 x 15,3 x 8,8 cm

Product specifications

compact trigger module
number of kits: 15
programmed sounds: 30
user sounds: 30
file format:
- Mac OSX: WAV, AIFF, MP3, AAC, Apple Lossless
- Windows: WAV (44.1 kHz, 16/24-bit)
- iOS: WAV, AIFF, MP3, AAC, Apple Lossless
- Android: WAV (44.1 kHz, 16-bit), MP3
knobs: Sensitivity, Pitch, Decay, Level, Mode Select, Mute, Kit Shift, Power
2 trigger inputs for single and dual trigger pads (1 dual trigger pad for 2 trigger inputs)
mono output in MIX, mixes sound from trigger 1 and trigger 2
stereo output in INDIVIDUAL, Trigger 1 left, Trigger 2 right
power supply:
- 9V battery (included)
- 9V AC power adapter (not included)
- USB (standard USB B to USB A cable included)
dimensions: 150 x 95 x 60 mm
weight: 550 g
connectors:
- jack output (L/Mono, R)
- stereo jack
- headphone connector (stereo mini jack)
- 2x trigger inputs jack (TRS)
- MIDI in/out
- power adapter
- USB B (MIDI)
Compatible with:
- acoustic drum triggers, RT series
- drum pads, PD series, PDX series, BT-1
- cymbal pads, CY series
- bass drum pads, KD series
- pedal triggers, KT series
- footswitch, DP series, Boss FS-5U, FS-6, FS-7
- stereo split cable, PCS-31L
- drum monitor, PM series
