Allen & Heath ZEDi-10FX Analogue Mixer with Effects
Product no: 9000-0022-5673 Bax Music Warranty: This product comes with a 3-year warranty.

General

The ZED series by Allen & Heath is a range of compact mixing consoles that are designed to help musicians by way of a simple introduction to audio recording. This particular mixer, the ZEDi-10FX, is the most comprehensive model of their range as it contains a large selection of effects that vary from a simple reverb to an extreme delay, chorus, and flanger. Using the tap-tempo button, you can perform real-time adjustments to these effects, and with the two volume knobs, you can apply them per channel, or to either the total mix or the AUX. Thanks to the USB interface, you can record channels 1 through 4 and edit them live (using the included Cubase LE software).

The ZEDi-10FX: Jack-In the Box

Despite its modest size, the ZEDi-10FX is extremely versatile. It features four mono and two stereo channels, RCA input, AUX, FX outputs, and a headphones input. As mentioned previously, this mixer also functions as a USB interface, making it possible to record the total mix, AUX and effects as well as the first four mono channels. This mixer has a built-in preamp that's based on the legendary GS-R24 studio console, which means you can connect studio mics and guitars directly. A 3-band equalizer allows you the freedom to make your instruments sound exactly the way you want them to.

Tips or comments about this product

To connect the mixer to an iOS device, a Camera Connection Kit (30-pin devices) or a Lightning USB adapter can be used and is sold separately.
The Allen & Heath ZEDi-10FX comes including a Cubase LE license.

Specifications

Product features

Sustainable product	not specified
Number of mono channels	4
Number of stereo channels	2
Number of submasters	none
Type of mixer inputs	microphone input (XLR), balanced line input (TRS jack), Hi-Z input (TS jack)
Type of mixer outputs	balanced line output (XLR), balanced line output (TRS jack), unbalanced line output (RCA), stereo headphone output (TRS jack or mini jack)
Headphone output	yes
Inputs	no
Number of auxiliaries	1 - 2
Built-in audio player	no
Built-in audio interface	USB (4x4 I/O)
Number of microphone inputs	3 - 4
19 inches	no
Phantom power	yes
Volume control	knobs, faders
Built-in mixer effects	reverb/delay/modulation, channel EQ
Type of mixer	studio / PA mixer
Built-in effects	yes

Weight and dimensions including packaging

Weight (incl. packaging)	3,6 kg
Dimensions (incl. packaging)	46,0 x 35,0 x 16,5 cm

Product specifications

analogue mixer with built-in stereo USB interface
inputs:
- 4x XLR and TRS jack (mic/line/instr) with lo-cut
- 2x jack TRS L/R (line)
- RCA input
outputs:
- main out: 2x XLR
- headphones: stereo jack (PFL switch)
- +48-volt phantom power on channels 1 and 4 (switchable; DI on 1 and 2, line/pad on 3 and 4)
- per channel: gain, 3-band EQ, pan/ball, volume, headphone monitoring
USB interface
- for PC, Mac and iOS (see Tips)
- 4 channels in, 4 channels out
- USB output source selection: channels 1 - 4 (standard) / channels 1 - 2 and main mix / channels 1 - 2, AUX and effects
- mix: stereo in volume
- main mix/volume fader and stereo LED meter
- internal effects section (including reverb, delay, chorus, flanger)
- effects volume control (AUX and mix)
- tap-tempo switch
aux volume control
monitor volume control
headphones volume control
on/off switch
monitor source switchable
XLRs = MONS to switch the PFL between main out and headphones
included: power cable, USB AB cable (2 metres), Cubase LE, Cubasis LE app, user manual
